Mitsubishi MELSEC Q Series Programming Manual

12-56
3400
[REMOTE PASS. ERR.]
The head I/O number of the target module of the
remote password is set to other than 0
H
to 0FF0
H
.
■Collateral information
• Common information:-
• Individual information:-
■Diagnostic Timing
• At power-on/At reset/STOP→RUN
Change the head I/O number of the target module
to be within the 0
H
to 0FF0
H
range.
RUN:
Off
ERR.:
Flicker
CPU Status:
Stop
Qn(H)
*8
QnPH
QnPRH
QnU
*15
LCPU
[REMOTE PASS. ERR.]
The head I/O number of the target module of the
remote password is set to other than 0
H
to 07E0
H
.
■Collateral information
• Common information:-
• Individual information:-
■Diagnostic Timing
• At power-on/At reset/STOP→RUN
Change the head I/O number of the target module
to be within the 0
H
to 07E0
H
range.
Q02UCPU
[REMOTE PASS. ERR.]
For the start I/O number of the module targeted by
the remote password, the value outside the
following range is specified.
Q00JCPU: 0
H
to 1E0
H
Q00CPU/Q01CPU: 0
H
to 3E0
H
■Collateral information
• Common information:-
• Individual information:-
■Diagnostic Timing
• At power-on/At reset/STOP→RUN
Correct the start I/O number value of the module
targeted by the remote password within the
following range.
• Q00JCPU: 0
H
to 1E0
H
• Q00CPU/Q01CPU: 0
H
to 3E0
H
Q00J/Q00/Q01
*8
3401
[REMOTE PASS. ERR.]
Position specified as the head I/O number of the
remote password file is incorrect due to one of the
following reasons:
• Module is not loaded.
• Other than a the intelligent function module (I/O
module)
• The intelligent function module installed is other
than a serial communication module, modem
interface module, or Ethernet module.
• The function version of the serial communication
module and Ethernet module installed is A.
• The intelligent function module where remote
password is available is not mounted.
■Collateral information
• Common information:-
• Individual information:-
■Diagnostic Timing
• At power-on/At reset/STOP→RUN
Install the serial communication module, modem
interface module, or Ethernet module of function
version B or later in the position specified with the
start I/O No. of the remote password.
Qn(H)
*8
QnPH
QnPRH
QnU
[REMOTE PASS. ERR.]
The position specified with the start I/O number of
the remote password is invalid due to one of the
following reasons:
• No module
• The intelligent function module installed is other
than a serial communication module.
■Collateral information
• Common information:-
• Individual information:-
■Diagnostic Timing
• At power-on/At reset/STOP→RUN
In a position specified with a start I/O number of
the remote password, install the intelligent
function module where the remote password is
available.
LCPU
Error
Code
Error Contents and Cause Corrective Action
LED Status
CPU Status
Corresponding
CPU
