OTE
● An LED, not a bulb, is used in the centre console down
light. Contact a MITSUBISHI MOTORS Authorised
Service Point when there is a need for repair or replace-
ment.
Headlamps
E01003500785
Replacement of low beam (halogen lamp type)
1. When replacing the bulb on the left side of the vehicle,
remove the bolt (A) holding down the relay box and move
the relay box toward the rear of the vehicle.
1- Luggage room lamp: 8 W
2- Room lamp (rear): 8 W
3- Map & room lamps (front): 8 W
4- Foot lamps: 1.4 W
5- Centre console down light
6- Lower glove box lamp: 1.4 W
