8-32
Maintenance
8
*: Fusible link
Some fuses may not be installed on your vehicle, depend-
ing on the vehicle model or specifications.
The table above shows the main equipment corresponding
to each fuse.
The fuse box does not contain spare 7.5 A, 25 A or 30 A fuses.
If one of these fuses burns out, substitute with the following
fuse.
7.5 A: 10 A spare fuse
25 A: 20 A spare fuse
30 A: 30 A audio amp fuse
When using a substitute fuse, replace with a fuse of the correct
capacity as soon as possible.
19
Headlamp low
beam (right)
Halogen 10 A
20 ENG/POWER 10 A
21 Ignition coil 10 A
22 ENG/POWER 20 A
23 Fuel pump 15 A
24 Starter 30 A*
25
26 Anti-lock braking system 40 A*
27 Anti-lock braking system 30 A*
28
Air conditioning condenser
fan motor
30 A*
29 Radiator fan motor 40 A*
30 IOD IOD 30 A
31 Audio system amp 30 A
32 Diesel 30 A
33 Spare fuse 10 A
34 Spare fuse 15 A
35 Spare fuse 20 A
No. Symbol Electrical system Capacities
