Maintenance
8-33
8
Identification of fuse
Fuse replacement
1. Before replacing a fuse, always turn off the electrical cir-
cuit concerned and place the ignition switch in the
“LOCK” position.
2. Remove the fuse puller (A) from the inside of the fuse box
in the engine compartment.
7.5 A Brown
10 A Red
15 A Blue
20 A Yellow
25 A Natural (White)
30 A Green (fuse type) /Pink (fusible link type)
40 A Green (fusible link type)
