Maintenance
8-39
8
Replacement of low beam (discharge lamp type)
Replacement of high beam
E01007100053
1. When replacing the bulb on the right side of the vehicle,
remove the bolt (A) fastening the washer fluid reservoir
spout and move the spout in the rear direction.
2. While holding down the tab (B), pull out the socket (C).
3. Turn the bulb (D) anticlockwise and remove it.
WARNING
!
● Always consult a specialist when replacing the bulbs
of discharge headlamps.
This is because the power circuit, bulbs and elec-
trodes generate a high voltage that could cause an
electric shock.
To Next Page
