Maintenance
8-45
8
4. Remove the cover below the fog lamp that you will
replace.
Insert a minus screwdriver into the clip groove on the
cover to wedge out the clips (D) toward the vehicle body,
then remove the cover.
5. In order to secure space to work, remove the bolt (E) and
tilt the front fog lamp unit in the direction of the arrow.
