Maintenance
8-47
8
Rear fog lamp (driver’s side)
E01004100111
1. Open the lower gate and pull back the cover between the
passenger compartment and the lower gate.
2. Remove the cover after you remove each of the 4 clips (A)
by inserting a screw driver into the clip groove and lever-
ing it toward the vehicle body.
3. Remove the lamp mounting screws (B) and remove the
lamp unit.
To Next Page
