CAUTION
★Please pay attention to the forward and backward supporting portion when lift the sewing machine
head.
1) The forward supporting portion : Never lift the sewing machine head with the sliding plate (no.21).
Always lift the sewing machine with the left and right grips
(No.20).
21)
20)
2) The backward supporting portion : Support the base of the rear section of the arm (No.22) that is
jutting out and lift up while holding nearest the connecting section
of the arm's jutting section.
If the sewing machine 's lifted up only by the Y detector cover
(No.23), the Y detector mounting plate could bend and could
prevent correct operation.
23)22)
