Mitsubishi PLK-E2010R - Structure of the Machine

- 1 -
1. STRUCTURE OF THE MACHINE
The PLK-E2010R electronic pattern sewing machine is constructed with the following main parts.
1)
5)
11)
8)
2)
3)
4)
6)
7)
9)
10)
(No.1) Sewing machine head. (No.2) Thread stand. (No.3) Operation panel. (No.4) Control box.
(No.5) Emergency stop switch. (No.6) Work holder foot switch. (No.7) Start foot switch.
(No.8) Work holder. (N0.9) Steel stand. (No.10) Limi-servo motor. (No.11) Wooden table top.
