- 27 -
7-6 Adjustment of the wiper
1) Loosen the wiper set screw (No.3) and adjust the wiper (No.1) to be positioned where the wiper
(No.1) passes under the needle point (No.2) with about 2mm clearances right after the sewing
machine is stopped running at the needle upper position (the thread take up lever’s highest position).
3)
4)
1)
1)2)
2mm
NOTE When the presser foot position or the presser foot lift is changed, the wiper (No.1) may collide
with the presser foot (No.4). In that case, please do not use the wiper (No.1).
2) If do not use the wiper (No.1), cancel the wiper
function with the operation panel as follows.
a) Press the
MENU
MENU key at the normal
mode condition, then MENU MODE is
appeared.
b) Press the
Program
key. Then below
screen will be appeared.
c) Press the
Wiper
key.
d) And then press the [WIP] key and select the
[OFF] key.
To Next Page
