Mitsubishi PLK-E2010R - Maintenance; Cleaning and Oil Management

- 43 -
8. MAINTENANCE
CAUTION
★Please make sure to turn the power switch always OFF when clean up the sewing machine.
★Before or after the sewing operation, clean up the sewing machine and check the oil level in the oil
tank.
8-1 Cleaning
1) Turn the power switch OFF.
2) Remove the dust and the thread waste sticking around the threading parts or the shuttle hook area.
3) Check the oil level in the oil tank. If the oil is under the red mark level supply the oil to be over the red
mark level.
1)
8-2 Disposing of oil waste
If the waste oil is full filled in the oil bottle (No.1), remove the oil bottle (No.1) then, dispose of the waste
oil.
1)
