4
HARDWARE SPECIFICATIONS OF THE CPU MODULE
4.1 Performance Specifications
4.1.4 Redundant CPU
4 - 15
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
GENERAL SPECIFICATIONS
4
HARDWARE SPECIFICATIONS OF THE CPU MODULE
5
POWER SUPPLY MODULE
6
BASE UNIT AND EXTENSION CABLE
7
MEMORY CARD AND BATTERY
8
CPU MODULE START- UP PROCEDURES
*8 : For use of CC-Link IE controller network, check the versions of the CPU module and GX Developer. ( Appendix 2.2)
Remark
For the general specifications, refer to CHAPTER 3.
Table4.4 Performance Specifications
Item
Redundant CPU
Q12PRHCPU Q25PRHCPU
No. of device points
Special relay [SM] 2048 points (SM0 to 2047) (The number of device points is fixed.)
Special register [SD] 2048 points (SD0 to 2047) (The number of device points is fixed.)
Function input [FX] 16 points (FX0 to F) (The number of device points is fixed.)
Function output [FY] 16 points (FY0 to F) (The number of device points is fixed.)
Function register [FD] 5 points (FD0 to 4) (The number of device points is fixed.)
No. of device tracking words
Max. 100k words
( QnPRHCPU User's Manual (Redundant System))
Link direct device
Device for accessing the link device directly.
Exclusively used for CC-Link IE controller network
*8
and MELSECNET/H.
Specified form: J \X , J \Y , J \W , J \B , J \SW , J \SB
Intelligent function module device
Device for accessing the buffer memory of the intelligent function module directly.
Specified form: U \G
Latch range
L0 to 8191 (default) (Setting by parameters.)
(Latch range can be set up for B, F, V, T, ST, C, D, and W.)
RUN/PAUSE contact One contact can be set up in X0 to 1FFF for each of RUN and PAUSE. (Setting by parameters.)
Timer function
Year, month, date, hour, minute, second, and day-of-week
(leap year automatically identified)
Accuracy: -3.2 to +5.27s
(TYP.+2.07s)/d at 0
Accuracy: -2.77 to +5.27s
(TYP.+2.22s)/d at 25
Accuracy: -12.14 to +3.65s
(TYP.-2.89s)/d at 55
Allowable momentary power failure
time
Varies depending on the power supply module.
5VDC internal current consumption 0.89A
External dimensions
H 98mm (3.86inch)
W 55.2mm (2.17inch)
D 89.3mm (3.52inch)
Weight 0.30kg
