2
SYSTEM CONFIGURATION
2.1 System Configuration
2.1.4 Applicable Devices and Software
2 - 36
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
GENERAL
SPECIFICATIONS
4
HARDWARE
SPECIFICATIONS OF
THE CPU MODULE
5
POWER SUPPLY
MODULE
6
BASE UNIT AND
EXTENSION CABLE
7
MEMORY CARD AND
BATTERY
8
CPU MODULE START-
UP PROCEDURES
2.1.4 Applicable Devices and Software
This section describes the applicable devices and software packages for configuring a
system.
(1) Modules replaceable online
The modules controlled by the Process CPU or Redundant CPU can be replaced
online ( Section 12.4). The modules controlled by the Basic model QCPU, High
Performance model QCPU, Universal model QCPU, Motion CPU, or PC CPU module
cannot be replaced online.
The following modules in Table2.7 can be replaced online:
* 1: The intelligent function module mounted on the main base unit when the Redundant CPU is used
cannot be replaced online.
(2) Applicable software
(a) GX Developer and PX Developer versions applicable in the single CPU
system
* 1: When using PX Developer, use GX Developer version 7.20W or higher.
Table2.7 Modules replaceable online
Module type Restriction
Input module
No restriction
Output module
I/O composite module
Intelligent function module
Analog-digital converter module
Supporting with function version
C.
*1
Digital-analog converter module
Temperature input module
Temperature control module
Pulse input module
Table2.8 Applicable GX Developer and PX Developer
CPU module
Applicable software version
GX Developer PX Developer
Basic model QCPU Version 7.00A or later
N/A
High Performance model QCPU Version 4.00A or later
Process CPU
Q02PHCPU
Q06PHCPU
Version 8.68W or later Version 1.18U or later
Q12PHCPU
Q25PHCPU
Version 7.10L or later
*1
Version 1.00A or later
Universal model
QCPU
Q02UCPU
Q03UDCPU
Q04UDHCPU
Q06UDHCPU
Version 8.48A or later
N/A
Q13UDHCPU
Q26UDHCPU
Version 8.62Q or later
Q03UDECPU
Q04UDEHCPU
Q06UDEHCPU
Q13UDEHCPU
Q26UDEHCPU
Version 8.68W or later
To Next Page
