Mitsubishi Q01CPU User Manual

App - 22
Appendix 1 External Dimensions
Appendix 1.7 Q8BAT-SET
APPENDICES
Appendix 1.7 Q8BAT-SET
Q8BAT
QC10BAT
Unit : mm (inch)
Diagram App.42 Q8BAT
Unit : mm (inch)
Diagram App.43 QC10BAT
5.8
(0.23)
4.5 (0.18)
98(3.86)
49(1.93)
87(3.43)
47.1(1.85)
55.2(2.17)
89.8(3.54)
Q8BAT
OUTPUT
3VDC
4.5mounting screws(M4 14)
4.5 5.1mounting screws(M4 14)
QC10BAT
55(2.17)
39(1.54)
1000(39.37)
30
(1.18)
