5.2 Specifications
5.2.1 Power supply module specifications
5
POWER SUPPLY MODULE
5.2 Specifications
5.2.1 Power supply module specifications
Table5.2 shows the specifications of the power supply modules.
Table5.2 Power supply module specifications
Item
Performance Specifications
Q61P-A1 Q61P-A2 Q61P Q62P
Base loading position Power supply module loading slot
Applicable base unit
Q3 B, Q3 DB, Q6 B
Input power supply
100 to 120VAC
(85 to 132VAC)
200 to 240VAC
(170 to 264VAC)
100 to 240VAC
(85 to 264VAC)
Input frequency
50/60Hz 5%
Input voltage
distortion factor
Within 5% ( Section 5.2.3)
Max. input apparent
power
105VA 120VA 105VA
Max. input power ----
Inrush current
20A within 8ms
*5
Rated
output
current
5VDC 6A 3A
24VDC ---- 0.6A
External output
voltage
----
24VDC 10%
Overcurrent
protection
*1
5VDC 6.6A or more 3.3A or more
24VDC ---- 0.66A or more
Overvoltage
protection
*2
5VDC 5.5 to 6.5V
24VDC ----
Efficiency 70% or more 65% or more
Allowable momentary
power failure period
*3
Within 20ms
Dielectric withstand
voltage
Across inputs/LG and outputs/FG
2830VAC rms/3 cycles (2000 m (6562 ft.))
Insulation resistance
Across inputs and outputs (LG and FG separated), across inputs and LG/FG, across outputs and FG/
LG 10M or more by insulation resistance tester
Noise durability
• By noise simulator of 1500Vp-p noise voltage, 1 s noise width and 25 to 60Hz noise frequency
• Noise voltage IEC61000-4-4, 2kV
Operation indication LED indication (Normal: ON (green), Error: OFF)
Fuse Built-in (Unchangeable by user)
+10%
-15%
+10%
-15%
+10%
-15%
