Appendix 1 External Dimensions
Appendix 1.3 Main base unit
APPENDICES
Appendix 1.3 Main base unit
(1) Q33B
(2) Q35B
Unit : mm (inch)
Diagram App.14 Q33B
Unit : mm (inch)
Diagram App.15 Q35B
7.5
(0.30)
I/O0
CPU
POWER
I/O2I/O1
44.1
(1.74)
15.5
(0.61)
98 (3.86)
7
(0.28)
189 (7.44)
5V
SG
FG
80 0.3
(3.15 0.01)
169 0.3 (0.65 0.01)
4-mounting screws (M4×14)
OUT
7.5
(0.30)
I/O0
CPU
POWER
I/O2I/O1 I/O3 I/O4
44.1
(1.74)
(0.61)
15.5
98 (3.86)
7
(0.28)
245 (9.65)
5V
SG
FG
4-mounting screws (M4×14)
80 0.3
(3.15 0.01)
224.5 0.3 (8.84 0.01)
OUT
