HOW TO USE THIS MANUAL
This manual is prepared for users to understand the hardware specifica-
tions of those modules such as the CPU modules, power supply modules,
and base units, maintenance and inspections of the system, and trouble-
shooting required when you use Q series programmable controllers.
The manual is classified roughly into three sections as shown below.
Remark
This manual does not explain the functions of the CPU module.
For these functions, refer to the manual shown below.
• High Performance model QCPU (Q Mode) User's Manual (Function
Explanation, Program Fundamentals)
Refer to the following manual for the multiple CPU system.
QCPU User's Manual (Multiple CPU System)
Refer to the following manual for the redundant system.
QnPRHCPU User's Manual (Redundant System)
1) Chapters 1 and 2 Describe the outline of the CPU module and the system
configuration.
The basics of the system configuration of CPU module are
described.
2) Chapters 3 to 7 Describe the general specifications indicating the operating
environments of the CPU module, power supply module, and base
units, and the performance specifications of these modules.
3) Chapters 8 to 12 Describe the overall maintenance such as the installation of the
CPU module, daily inspections, and troubleshooting.
