POWER SUPPLY MODULE
5.2 Specifications
5.2.1 Power supply module specifications
5 - 3
1
OVERVIEW
2
SYSTEM
CONFIGURATION
3
GENERAL
SPECIFICATIONS
4
HARDWARE
SPECIFICATIONS OF
THE CPU MODULE
5
POWER SUPPLY
MODULE
6
BASE UNIT AND
EXTENSION CABLE
7
MEMORY CARD AND
BATTERY
8
CPU MODULE START-
UP PROCEDURES
Table5.2 Power supply module specifications
Item
Performance Specifications
Q61P-A1 Q61P-A2 Q61P Q62P
Contact output section
Application
ERR
contact ( Section 5.3)
Rated
switching
voltage,
current
24VDC, 0.5A
Minimum
switching load
5VDC, 1mA
Response time OFF to ON: 10ms max. ON to OFF: 12ms max.
Life
Mechanical : More than 20 million times
Electrical : More than 100 thousand times at rated switching voltage, current
Surge
suppressor
No
Fuse No
Terminal screw size
M3.5 7
Applicable wire size
0.75 to 2mm
2
Applicable solderless
terminal
RAV1.25 - 3.5, RAV2 - 3.5
Applicable tightening
torque
0.66 to 0.89N•m
External
dimensions
H 98mm (3.86inch)
W 55.2mm (2.17inch)
D 90mm (3.55inch)
Weight 0.31kg 0.40kg 0.39kg
