5.2 Specifications
5.2.1 Power supply module specifications
5
POWER SUPPLY MODULE
Table5.3 Power supply module specifications
Item
Performance Specifications
Q63P
Base loading position Power supply module loading slot
Applicable base unit
Q3 B, Q3 DB, Q6 B
Input power supply
24VDC
(15.6 to 31.2VDC)
Input frequency ----
Input voltage
distortion factor
----
Max. input apparent
power
----
Max. input power 45W
Inrush current 100A within 1ms (at 24VDC input)
Rated
output
current
5VDC 6A
24VDC ----
External output
voltage
----
Overcurrent
protection
*1
5VDC 6.6A or more
24VDC ----
Overvoltage
protection
*2
5VDC 5.5 to 6.5V
24VDC ----
Efficiency 70% or more
Allowable momentary
power failure time
*3
Within 10ms
(at 24VDC input)
Dielectric withstand
voltage
500VAC across primary and 5VDC
Insulation resistance
10M or more by insulation resistance tester
Noise durability
By noise simulator of 500Vp-p noise voltage, 1 s noise width and 25 to 60Hz noise frequency
Operation indication LED indication (Normal: ON (green), Error: OFF)
Fuse Built-in (Unchangeable by user)
+30%
-35%
