5.2 Specifications
5.2.1 Power supply module specifications
5
POWER SUPPLY MODULE
Table5.4 Power supply module specifications
Item
Performance Specifications
Q64P Q64PN
Base loading position Power supply module loading slot
Applicable base unit
Q3 B, Q3 DB, Q6 B
Input power supply
100 to 120VAC/200 to 240VAC
(85V to 132VAC/170 to 264VAC)
100 to 240VAC
(85V to 264VAC)
Input frequency
50/60Hz 5%
Input voltage
distortion factor
Within 5% ( Section 5.2.3)
Max. input apparent
power
160VA
Inrush current
20A within 8ms
*5
Rated
output
current
5VDC 8.5A
24VDC ----
Overcurrent
protection
*1
5VDC 9.9A or more
24VDC ----
Overvoltage
protection
*2
5VDC 5.5 to 6.5V
24VDC ----
Efficiency 70% or more
Allowable momentary
power failure time
*3
Within 20ms
Dielectric withstand
voltage
Across inputs/LG and outputs/FG
2830VAC rms/3 cycles (2000 m (6562 ft.))
Insulation resistance
Across inputs and outputs (LG and FG separated), across inputs and LG/FG,
across outputs and FG/LG 10M or more by insulation resistance tester
Noise durability
• By noise simulator of 1500Vp-p noise voltage, 1 s noise width and 25 to 60Hz noise frequency
• Noise voltage IEC61000-4-4, 2kV
Operation indication LED indication (Normal: ON (green), Error: OFF)
Fuse Built-in (Unchangeable by user)
+10%
-15%
+10%
-15%
