Mitsubishi Q01CPU User Manual

5 - 8
5.2 Specifications
5.2.1 Power supply module specifications
5
POWER SUPPLY MODULE
Table5.5 Power supply module specifications
Item
Performance Specifications
Q61SP
Base loading position Power supply module loading slot
Applicable base unit
Q3 SB
Input power supply
100 to 240VAC
(85 to 264VAC)
Input frequency
50/60Hz 5%
Input voltage
distortion factor
Within 5% ( Section 5.2.3)
Max. input apparent
power
40VA
Inrush current
20A within 8ms
*5
Rated
output
current
5VDC 2A
24VDC ----
Overcurrent
protection
*1
5VDC 2.2A or more
24VDC ----
Overvoltage
protection
*2
5VDC 5.5 to 6.5V
24VDC ----
Efficiency 70% or more
Allowable momentary
power failure time
*3
Within 20ms (AC100VAC or more)
Dielectric withstand
voltage
Across inputs/LG and outputs/FG
2830VAC rms/3 cycles (2000 m (6562 ft.))
Insulation resistance
Across inputs and outputs (LG and FG separated), across inputs and LG/FG,
across outputs and FG/LG 10M or more by insulation resistance tester
Noise durability
• By noise simulator of 1500Vp-p noise voltage, 1 s noise width and 25 to 60Hz noise frequency
• Noise voltage IEC61000-4-4, 2kV
Operation indication LED indication (Normal: ON (green), Error: OFF)
Fuse Built-in (Unchangeable by user)
Contact output section
Application
ERR
contact ( Section 5.3)
Rated
switching
voltage,
current
24VDC, 0.5A
Minimum
switching load
5VDC, 1mA
Response time OFF to ON: 10ms max. ON to OFF: 12ms max.
Life
Mechanical : More than 20 million times
Electrical : More than 100 thousand times at rated switching voltage, current
Surge
suppressor
No
Fuse No
+10%
-15%
