POWER SUPPLY MODULE
5.2 Specifications
5.2.1 Power supply module specifications
5 - 19
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
GENERAL SPECIFICATIONS
4
HARDWARE SPECIFICATIONS OF THE CPU MODULE
5
POWER SUPPLY MODULE
6
BASE UNIT AND EXTENSION CABLE
7
MEMORY CARD AND BATTERY
8
CPU MODULE START- UP PROCEDURES
POINT
*8: The overcurrent protection shuts off the +15VDC circuit if a current higher than the
specified value flows in the circuit and:
(a) Both +15VDC and -15VDC are switched off if overcurrent has occurred at +15V;
or
(b) -15VDC is switched off but +15V remains output if overcurrent has occueered at -
15V; and
(c) The power supply module LED is switched off or dimly lit due to 15VDC voltage
drop.
If this device is activated, turn off the input power supply and eliminate the cause
such as insufficient current capacity or short before restarting the system.
Table5.12 Power supply module specifications
Item
Performance Specifications
A68P
Location I/O module slot
Number of points occupied 2 slots occupied, 1 slot 16 points
Input voltage
100 to 120V AC
(85 to 132V AC)
200 to 240V AC
(170 to 264V AC)
Input frequency
50/60Hz 5%
Max. input apparent power 95VA
Inrush current 20A, within 8ms
Rated output
current
+15VDC 1.2A
-15VDC 0.7A
Overcurrent
protection
*8
+15VDC 1.64A or more
-15VDC 0.94A or more
Efficiency 65% or more
Power indicator Power LED display (Normal: ON (green), error: OFF)
Power ON monitor output
Contact output
Switched on if +15V DC output is +14.25V or higher or -15V DC output is -14.25V or lower.
Min. contact switching load: 5V DC, 10mA
Min. contact switching load: 264V AC (R load)
Terminal screw size
M3 0.5(0.02) 6(0.24)
Wire size
0.75 to 2mm
2
(18 to 14 AWG)
Soldreless terminal V1.25 - 4, V2 - YS4A, V2 - S4, V2 - YS4A
External
dimensions
H 250mm(9.84inch)
W 75.5mm(2.97inch)
D 121mm(4.76inch)
Weight 0.9kg(1.98lb)
+10%
-15%
+10%
-15%
