Mitsubishi Q01CPU User Manual

6 - 2
6.1 Base Unit
6.1.1 Specification Table
6
BASE UNIT AND EXTENSION CABLE
(2) Slim type main base unit
(3) Redundant power main base unit
Table6.2 Slim type main base unit specifications
Item
Type
Q32SB Q33SB Q35SB
Number of I/O modules
installed
23 5
Possibility of extension Cannot connect extension modules.
Applicable module Q series modules
5 VDC internal current
consumption
0.09A 0.10A
Mounting hole size
M4 screw hole or 4.5 hole (for M4 screw)
External dimensions
H 98mm (3.86inch)
W 114mm (4.49inch) 142mm (5.59inch) 197.5mm (7.78inch)
D 18.5mm (0.73inch)
Weight 0.12kg 0.15kg 0.21kg
Attachment
Mounting screw M4 12 4 pieces (DIN rail mounting adapter to be sold separately)
DIN rail mounting adapter
type
Q6DIN3
Table6.3 Redundant power main base unit specifications
Item
Type
Q38RB
Number of I/O modules
installed
8
Possibility of extension Extendable
Applicable module Q series modules
5 VDC internal current
consumption
0.12A
Mounting hole size
M4 screw hole or 4.5 hole (for M4 screw)
External dimensions
H 98mm (3.86inch)
W 439mm (17.28inch)
D 44.1mm (1.74inch)
Weight 0.47kg
Attachment
Mounting screw M4 14 5 pieces (DIN rail mounting adapter to be sold separately)
DIN rail mounting adapter
type
Q6DIN1
