Mitsubishi Q01CPU User Manual

12 - 12
12.2 Troubleshooting
12.2.5 Flowchart for when the "POWER" LED turns off
12
TROUBLESHOOTING
Diagram 12.5 Flowchart for when the "POWER" LED is turned off
Does the
total current exceed the
rated output current of the power
supply module?
Reexamine the system configuration
to make the total current less than
the rated output current of the power
supply module
Hardware fault
Execute operation checks in due
order, starting with the minimum
system.
For the module that does not
operate, please contact your local
Mitsubishi service center or
representative, explaining a detailed
description of the problem.
Check the sum of internal current
consumptions of the modules that
comprise the system.
No
Yes
(From previous page)
Hardware fault
check operations in the order
starting with the minimum
system.
If the module will not work ,
please consalt your local
nearest Mitsubishi or
representative, explaining a detailed
description of the problem.
