Mitsubishi Q01CPU User Manual

12
TROUBLESHOOTING
12.3 Error Code List
12.3.3 Error code list (1000 to 1999)
12 - 61
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
1101
The sequence program storing built-in
RAM/program memory in the CPU
module is faulty.
• Take noise reduction measures.
• Reset the CPU module and RUN it
again. If the same error is displayed
again,this suggests a CPU module
hardware fault.(Contact your local
Mitsubishi representative.)
1102
The work area RAM in the CPU module
is faulty.
• Take noise reduction measures.
• Reset the CPU module and RUN it
again. If the same error is displayed
again,this suggests a CPU module
hardware fault.(Contact your local
Mitsubishi representative.)
1103
The device memory in the CPU module
is faulty.
• Take noise reduction measures.
• When indexing is performed, check
the value of index register to see if it
is within the device range.
• Reset the CPU module and RUN it
again. If the same error is displayed
again,this suggests a CPU module
hardware fault.(Contact your local
Mitsubishi representative.)
• The device memory in the CPU
module is faulty.
• The device out of range is accessed
due to indexing, and the device for
system is overwritten.
Qn(H)
*8
QnPH
*8
QnPRH
*9
1104
The address RAM in the CPU module is
faulty.
• Take noise reduction measures.
• Reset the CPU module and RUN it
again.If the same error is displayed
again, this suggests a CPU module
hardware fault. (Contact your local
Mitsubishi representative.)
1105
The system RAM in the CPU module is
faulty.
Q4AR
The CPU memory in the CPU module is
faulty.
Q00J/Q00/Q01
QnU
The CPU shared memory in the CPU
module is faulty.
Qn(H)
*4
QnPH
QnPRH
QnU
Error
Code
(SD0)
Error Contents and Cause Corrective Action
Corresponding
CPU
*4 Function version is B or later.
*5 Function version is A.
*6 The module whose first 5 digits of serial No. is 04101 or later.
*7 The module whose first 5 digits of serial No. is 07032 or later.
*8 The module whose first 5 digits of serial No. is 08032 or later.
*9 The module whose first 5 digits of serial No. is 09012 or later.
*10 The Universal model QCPU except the Q02UCPU.
*11 The Q13UDHCPU and Q26UDHCPU
*12 This applies to the QnUDE(H)CPU.
*13 The module whose first 5 digits of serial No. is 10042 or later.
