Q6 B
Generic term for Q63B, Q65B, Q68B and Q612B extension base unit on which Q Series
power supply module, I/O module, intelligent function module can be mounted.
Q6 RB
Other name for Q68RB redundant power supply extension base unit on whichredundant
power supply module, Q series I/O module, and intelligent function module can be
mounted.
Q6 WRB
Other name for Q65WRB extension base unit for redundant system on which redundant
power supply module, Q series I/O module, and intelligent function module can be
mounted.
QA1S6 B
Generic term for QA1S65B and QA1S68B extension base units on which AnS Series
power supply module, I/O module, special function module can be mounted.
QA6 B
Generic term for QA65B and QA68B extension base units on which the A series power
supply module, A series I/O modules and special function modules can be mounted.
A5 B
Generic term for A52B, A55B, and A58B extension base units on which A series I/O
module and special function module can be mounted without power supply.
A6 B
Generic term for A62B, A65B, and A68B extension base units on which A series I/O
module and special function module can be mounted.
QA6ADP Abbreviation for QA6ADP QA conversion adapter module.
QA6ADP+A5 B/A6 B
Abbreviation for A large type extension base unit on which QA6ADP is mounted.
Main base unit
Generic term for Q3 B, Q3 SB, Q 3RB and Q3 DB.
Extension base unit
Generic term for Q5 B, Q6 B, Q6 RB, Q6 WRB, QA1S6 B, QA6 B and
QA6ADP+A5 B/A6 B.
Slim type main base unit
Other name for Q3 SB.
Redundant power main base unit
Other name for Q3 RB.
Redundant power extension base
unit
Other name for Q6 RB.
Redundant extension base unit
Other name for Q6 WRB.
Multiple CPU high speed main
base unit
Other name for Q3 DB.
Base unit
Generic term for main base unit, extension base unit, slim type main base unit,
redundant power main base unit, redundant power extension base unit, redundant
extension base unit and Multiple CPU high speed main base unit.
Redundant power supply base
unit
Generic term for redundant power main base unit and redundant power extension base
unit.
Redundant base unit
Generic term for redundant power main base unit, redundant power extension base unit,
and redundant type extension base unit.
Extension cable Generic term for QC05B, QC06B, QC12B, QC30B, QC50B, QC100B extension cables.
Tracking cable Generic term for QC10TR and QC30TR tracking cables for Redundant CPU.
Q series power supply module
Generic term for Q61P-A1, Q61P-A2, Q61P, Q62P, Q63P, Q64P and Q64PN power
supply modules.
Slim type power supply module Abbreviation for Q61SP slim type power supply module.
Redundant power supply module Generic term for Q63RP and Q64RP redundant power supply module.
AnS series power supply module Generic term for A1S61PN, A1S62PN and A1S63P power supply modules.
A series power supply module
Generic term for A61P, A61PN, A62P, A63P, A68P, A61PEU and A62PEU power supply
modules.
Power supply module
Generic term for Q series power supply modules, AnS series power supply modules,
A series power supply modules, slim type power supply module and redundant power
supply module.
Battery
Generic term for Q6BAT, Q7BAT and Q8BAT CPU module batteries, Q2MEM-BAT
SRAM card battery, and Q3MEM-BAT SRAM card battery.
