Mitsubishi Q01CPU User Manual

12
TROUBLESHOOTING
12.3 Error Code List
12.3.5 Error code list (3000 to 3999)
12 - 131
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
*4 The module whose first 5 digits of serial No. is 04012 or later.
*5 The module whose first 5 digits of serial No. is 07032 or later.
*6 The MELSECNET/H module whose first 5 digits of serial No. is 08102 or later.
*7 The module whose first 5 digits of serial No. is 09012 or later.
*8 The Universal model QCPU except the Q02UCPU.
*9 The module whose first 5 digits of serial No. is 10042 or later.
Error
Code
(SD0)
Error Contents and Cause Corrective Action
Corresponding
CPU
3000
In a multiple CPU system, the intelligent
function module under control of
another CPU is specified in the interrupt
pointer setting of the PLC parameter.
• Specify the head I/O number of the
intelligent function module under
control of the host CPU.
• Delete the interrupt pointer setting of
the parameter.
Qn(H)
*1
QnPH
QnU
The PLC parameter settings for timer
time limit setting, the RUN-PAUSE
contact, the common pointer number,
general data processing, number of
empty slots, system interrupt settings,
baud rate setting, and service
processing setting are outside the range
that can be used by the CPU module.
• Read the individual information of the
error using the peripheral device,
check the parameter item
corresponding to the numerical value
(parameter No.), and correct it.
• Rewrite corrected parameters to the
CPU module, reload the CPU power
supply and/or reset the module.
• If the same error occurs, it is thought
to be a hardware error. (Contact your
local Mitsubishi representative.)
Rem
In a program memory check, the check
capacity has not been set within the
range applicable for the CPU module.
QnPH
QnPRH
*5
The parameter settings in the error
individual information (special register
SD16) are illegal.
The ATA card is set to the memory card
slot when the specified drive for the file
register is set to "memory card (ROM)"
and [Use the following file] or [Use the
same file name as the program] (either
one is allowed) is set in the PLC file
setting.
QnU
3001 The parameter settings are corrupted.
Rem
