12
TROUBLESHOOTING
12.3 Error Code List
12.3.5 Error code list (3000 to 3999)
12 - 153
9
EMC AND LOW
VOLTAGE
DIRECTIVES
10
LOADING AND
INSTALLATION
11
MAINTENANCE AND
INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
3104
• The Ethernet, MELSECNET/H and
MELSECNET/10 use the same
network number.
• The network number, station number
or group number set in the network
parameter is out of range.
• The specified I/O number is outside
the range of the used CPU module.
• The Ethernet-specific parameter
setting is not normal.
• Correct and write the network
parameters.
• If the error occurs after correction, it
suggests a hardware fault. (Contact
your local Mitsubishi representative.)
Rem
3105
In a multiple CPU system, the Q series
CC-Link module under control of
another station is specified as the head
I/O number of the CC-Link network
parameter.
• Delete the CC-Link network
parameter of the Q series CC-Link
module under control of another
station.
• Change the setting to the start I/O
number of the Q series CC-Link
module under control of the host
station.
Q00/Q01
*1
Qn(H)
*1
QnPH
QnU
• Though the number of CC-Link
modules set in the network
parameters is one or more, the
number of actually mounted modules
is zero.
• The start I/O number in the common
parameters is different from that of
the actually mounted module.
• The station type of the CC-Link
module count setting parameters is
different from that of the actually
mounted station.
• Correct and write the network
parameters.
• If the error occurs after correction, it
suggests a hardware fault. (Contact
your local Mitsubishi representative.)
Rem
• CC-Link module whose station type is
set to “master station (compatible
with redundant function)” is mounted
on the extension base unit in the
redundant system.
• CC-Link module whose station type is
set to “master station (extension
base)” is mounted on the main base
unit in the redundant system.
QnPRH
*6
The contents of the Ethernet parameter
are incorrect.
Write after correcting parameters. QnA
Error
Code
(SD0)
Error Contents and Cause Corrective Action
Corresponding
CPU
*4 The module whose first 5 digits of serial No. is 04012 or later.
*5 The module whose first 5 digits of serial No. is 07032 or later.
*6 The MELSECNET/H module whose first 5 digits of serial No. is 08102 or later.
*7 The module whose first 5 digits of serial No. is 09012 or later.
*8 The Universal model QCPU except the Q02UCPU.
*9 The module whose first 5 digits of serial No. is 10042 or later.
