12
TROUBLESHOOTING
12.3 Error Code List
12.3.6 Error code list (4000 to 4999)
12 - 173
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
*3 The module whose first 5 digits of serial No. is 04012 or later.
*4 The module whose first 5 digits of serial No. is 07012 or later.
*5 The module whose first 5 digits of serial No. is 07032 or later.
*6 The module whose first 5 digits of serial No. is 09012 or later.
*7 The Universal model QCPU except the Q02UCPU.
*8 This applies to the QnUDE(H)CPU.
4200
No NEXT instruction was executed
following the execution of a FOR
instruction.
Alternatively, there are fewer NEXT
instructions than FOR instructions.
Read the common information of the
error using the peripheral device, check
error step corresponding to its
numerical value (program error
location), and correct the problem.
4201
A NEXT instruction was executed
although no FOR instruction has been
executed.
Alternatively, there are more NEXT
instructions than FOR instructions.
4202
More than 16 nesting levels are
programmed.
Keep nesting levels at 16 or under.
4203
A BREAK instruction was executed
although no FOR instruction has been
executed prior to that.
Read the common information of the
error using the peripheral device, check
error step corresponding to its
numerical value (program error
location), and correct the problem.
4210
The CALL instruction is executed, but
there is no subroutine at the specified
pointer.
4211
There was no RET instruction in the
executed subroutine program.
4212
The RET instruction exists before the
FEND instruction of the main routine
program.
4213
More than 16 nesting levels are
programmed.
Keep nesting levels at 16 or under.
4220
Though an interrupt input occurred, the
corresponding interrupt pointer does not
exist.
Read the common information of the
error using the peripheral device, check
error step corresponding to its
numerical value (program error
location), and correct the problem.
4221
An IRET instruction does not exist in the
executed interrupt program.
4223
The IRET instruction exists before the
FEND instruction of the main routine
program.
• The IRET instruction was executed in
the fixed scan execution type
program.
• The STOP instruction was executed
in the fixed scan execution type
program.
QnU
4225
The interrupt pointer for the module
mounted on the extension base unit is
set in the redundant system.
Delete the setting of interrupt pointer for
the module mounted on the extension
base unit, since it cannot be used.
QnPRH
*6
Error
Code
(SD0)
Error Contents and Cause Corrective Action
Corresponding
CPU
