12
TROUBLESHOOTING
12.3 Error Code List
12.3.8 Error code list (6000 to 6999)
12 - 195
9
EMC AND LOW
VOLTAGE
DIRECTIVES
10
LOADING AND
INSTALLATION
11
MAINTENANCE AND
INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
6036
A difference in the remote I/O
configuration of the MELSECNET/H
multiplexed remote I/O network
between the control system and
standby system of a redundant system
was detected.
(This can be detected from the control
system or standby system of the
redundant system.)
Check the network cables of the
MELSECNET/H multiplexed remote I/O
network for disconnection.
QnPRH
6040
In a redundant system, the memory
card installation status (installed/not
installed) differs between the control
system and standby system.
Match the memory card installation
statuses (set/not set) of the control
system and standby system.
6041
In a redundant system, the memory
card type differs between the control
system and standby system.
Match the memory card types of the
control system and standby system.
6050
The function inexecutable in the debug
mode or operation mode (backup/
separate mode) was executed.
(This can be detected from the control
system or standby system of the
redundant system.)
Execute the function executable in the
debug mode or operation mode
(backup/separate mode).
QnPRH
6060
In a redundant system, the operation
mode (backup/separate) differs
between the control system and
standby system.
(This can be detected from the standby
system of the redundant system.)
Match the operation modes of the
control system and standby system.
6061
6062
Both System A and B are in the same
system status (control system).
(This can be detected from the system
B of the redundant system.)
Power the CPU module (System B)
which resulted in a stop error, OFF and
then ON.
QnPRH
Error
Code
(SD0)
Error Contents and Cause Corrective Action
Corresponding
CPU
*1 The module whose first 5 digits of serial No. is 09012 or later.
To Next Page
