TROUBLESHOOTING
12.3 Error Code List
12.3.11 Error codes returned to request source during communication with CPU module
12 - 225
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
Table12.12 Error code
Error code
(Hexadecimal)
Error item Error details Corrective action
4040
H
Intelligent
function
module
specification
error
The request contents cannot be executed in
the specified intelligent function module.
Check whether the specified module is the intelligent
function module having the buffer memory.
4041
H
The access range exceeds the buffer memory
range of the specified intelligent function
module.
Check the header address and access number of points
and access using a range that exists in the intelligent
function module.
4042
H
The specified intelligent function module
cannot be accessed.
• Check that the specified intelligent function module is
operating normally.
• Check the specified module for a hardware fault.
4043
H
The intelligent function module does not exist
in the specified position.
Check the I/O No. of the specified intelligent function
module.
4044
H
A control bus error occurred during access to
the intelligent function module.
Check the specified intelligent function module and other
modules and base units for a hardware fault.
4050
H
Protect error
The request contents cannot be executed
because the memory card write protect switch
is on.
Turn off the memory card write protect switch.
4051
H
The specified device memory cannot be
accessed.
Check the following and make it countermeasures.
• Is the memory one that can be used?
• Is the specified drive memory correctly installed?
4052
H
The specified file attribute is read only so the
data cannot be written.
Do not write data in the specified file.
Or change the file attribute.
4053
H
An error occurred when writing data to the
specified drive memory.
Check the specified drive memory.
Or reexecute write after changing the corresponding
drive memory.
4054
H
An error occurred when deleting the data in
the specified drive memory.
Check the specified drive memory.
Or re-erase after replacing the corresponding drive
memory.
4060
H
Online
registration
error
The online debug function is being executed
by the other peripheral device.
• Execute the function again after the operation of the
other peripheral device has ended.
• When the operation was suspended by the other
peripheral device, execute the function again after
executing it on the other peripheral device to normally
complete the operation.
4061
H
Communication of the online debug function
was unsuccessful.
• Execute communication after the registering the online
debug function (e.g.online program change/trace/
conditional monitor).
• Execute again after checking the communication route
such as the communication cable.
4063
H
The registered number of locked files
exceeded the maximum value.
Execute again after file access by the other peripheral
device has ended.
4064
H
The specified data of the online debug
function is incorrect.
• Check the set data of the online debug function (e.g.
online program change/trace/conditional monitor).
• Execute again after checking the communication route
such as the communication cable.
