12 - 308
12.8 Special Register List
12
TROUBLESHOOTING
Remark
*6 : Extensions are shown below.
Table12.46 Extension name
SDn SDn+1
Extension
Name
File Type
Higher 8 bits Lower 8 bits Higher 8 bits
51H 50H 41H QPA Parameters
51H 50H 47H QPG
• Sequence program
• SFC program
51H 43H 44H QCD Device comment
51H 44H 49H QDI Initial device value
51H 44H 52H QDR File register
51H 44H 53H QDS
Simulation data
(For QnA)
51H 44H 4CH QDL
Local device
(Other than the Basic model QCPU)
51H 54H 44H QTD
Sampling trace data
(Other than the Basic model QCPU)
51H 54H 4CH QTL Status latch data (For QnA)
51H 54H 50H QTP Program trace data (For QnA)
51H 54H 52H QTR
SFC trace file
(For QnA)
51H 46H 44H QFD
Breakdown history data
(Other than the Basic model QCPU and
the Universal model QCPU)
51H 53H 54H QST
SP.DEVST/S.DEVLD instruction file
(For Universal model QCPU only)
To Next Page
