12.8 Special Register List
12 - 315
9
EMC AND LOW VOLTAGE DIRECTIVES
10
LOADING AND INSTALLATION
11
MAINTENANCE AND INSPECTION
12
TROUBLESHOOTING APPENDICES INDEX
Table12.47 Special register
Number Name Meaning Explanation
Set by
(When Set)
Corres-
ponding
ACPU
D9
Corresponding
CPU
SD201 LED status
Status of
CPU-LED
• The following bit patterns store the status of the LEDs on the CPU
module:
• 0 is off, 1 is on, and 2 is flicker.
1): RUN 5): BOOT
2): ERR. 6): Empty Mode bit pattern
3): USER 7): Empty 0: OFF 1: Green
4): BAT. 8): MODE 2: Orange
(The Basic model QCPU does not include 3) to 8).)
S (Status
change)
New
Q00J/Q00/Q01
Qn(H)
QnPH
QnPRH
• The following bit patterns store the status of the LEDs on the CPU
module:
• 0 is off, 1 is on, and 2 is flicker.
1): RUN 5): BOOT
2): ERROR 6): Empty
3): USER 7): Empty
4): BAT. 8): MODE
S (Status
change)
New QnU
• The following bit patterns store the status of the LEDs on the CPU
module:
• 0 is off, 1 is on, and 2 is flicker
1): RUN 5): BOOT
2): ERROR 6): CARD A (memory card A)
3): USER 7): CARD B (memory card B)
4): BAT.ALARM 8): Empty
S (Status
change)
New
QnA
SD202
LED off
command
Bit pattern of LED
that is turned off
• Stores bit patterns of LEDs turned off
(Only USER and BOOT enabled)
• Turned off at 1, not turned off at 0
UNew
• Specify the LEDs to be turned off using this register, and turn SM202
from OFF to ON to turn off the specified LEDs.
USER and BOOT can be specified as the LEDs to be turned off.
• Specify the LEDs to be turned off in the following bit pattern.
(Turned off at 1, not be turned off at 0.)
UNew
Qn(H)
QnPH
QnPRH
QnU
b15 b12b11 b8 b7 b4b3 b0
1)2)4) 3)5)6)8) 7)
to tototo
b15 b12b11 b8 b7 b4b3 b0
1)2)4) 3)5)6)8) 7)
to tototo
b15 b12b11 b8 b7 b4b3 b0
1)2)4) 3)5)6)8) 7)
to tototo
b15 b8 b4 b0
USER
LED
BOOT
LED
Fixed
to 0
Fixed
to 0
Fixed
to 0
