Mitsubishi Q01CPU User Manual

12 - 328
12.8 Special Register List
12
TROUBLESHOOTING
Table12.50 Special register
Number Name Meaning Explanation
Set by
(When Set)
Corres-
ponding
ACPU
D9
Corresponding
CPU
SD604
Memory card
use conditions
Memory card use
conditions
• The use conditions for memory card (A) are stored as bit patterns .
(In use when ON)
• The significance of these bit patterns is indicated below:
S (Status
change)
New
Qn(H)
QnPH
QnPRH
Memory card A
use conditions
Memory card A
use conditions
• The use conditions for memory card A are stored as bit patterns.
(In use when ON)
• The significance of these bit patterns is indicated below:
S (Status
change)
New QnA
Memory card
use conditions
Memory card use
conditions
• The use conditions for memory card (A) are stored as bit patterns .
(In use when ON)
• The significance of these bit patterns is indicated below:
*1: Turned ON at boot start and OFF at boot completion.
*2: Turned ON when reflection of device initial value is started and OFF
when reflection of device initial value is completed.
S (Status
change)
New QnU
b0 : Boot operation (QBT)
b1 : Parameters (QPA)
b2 : Device comments (QCD)
b3 : Device initial value (QDI)
b4 : File register R (QDR)
b5 : Sampling trace (QTD)
b6 : Not used
b7 : Not used
b8 : Not used
b9 : CPU fault history (QFD)
b10 : Not used
b11 : Local device (QDL)
b12 : Not used
b13 : Not used
b14 : Not used
b15 : Not used
b0 : Boot operation (QBT)
b1 : Parameters (QPA)
b2 : Device comments (QCD)
b3 : Device initial value (QDI)
b4 : File R (QDR)
b5 : Sampling trace (QTD)
b6 : Status latch (QTL)
b7 : Program trace (QTP)
b8 : Simulation data (QDS)
b9 : CPU fault history (QFD)
b10 : SFC trace (QTR)
b11 : Local device (QDL)
b12 : Not used
b13 : Not used
b14 : Not used
b15 : Not used
b0 : Boot operation (QBT)
*1
b1 : Parameters (QPA)
b2 : Device comments (QCD)
b3 : Device initial value (QDI)
*2
b4 : File register R (QDR)
b5 : Sampling trace (QTD)
b6 : Not used
b7 : Not used
b8 : Not used
b9 : Not used
b10 : Not used
b11 : Local device (QDL)
b12 : Not used
b13 : Not used
b14 : Not used
b15 : Not used
