12 - 338
12.8 Special Register List
12
TROUBLESHOOTING
*14: The Universal model QCPU except the Q02UCPU.
*15: The range is from 1 to 9 for the Q03UDCPU, Q04UDHCPU, and Q06UDHCP whose first 5 digits of serial number is "10012" or earlier.
(Default: 2 Or when setting other than 1 to 9, the register operates as 9).
Table12.51 Special register
Number Name Meaning Explanation
Set by
(When Set)
Corres-
ponding
ACPU
D9
Corresponding
CPU
SD796
Maximum
number of blocks
used for the
multiple CPU
high-speed
transmission
dedicated
instruction
setting (for CPU
No.1)
Maximum
number of blocks
range for
dedicated
instructions
Range: 1 to 7
(Default: 2 Or
when setting
other than 1 to 7,
the register
operates as 7).
• Specifies the maximum number of blocks used for the multiple CPU
high-speed transmission dedicated instruction (target CPU=CPU No.1).
When the dedicated instruction of Multiple CPU transmission is
executed to the CPU No.1, and the number of empty blocks of the
dedicated instruction transmission area is less than the setting value of
this register, SM796 is turned ON, which is used as the interlock signal
for consecutive execution of the dedicated instruction of Multiple CPU
transmission.
U (At 1 scan
after RUN)
New
QnU
*14*15
SD797
Maximum
number of blocks
used for the
multiple CPU
high-speed
transmission
dedicated
instruction
setting (for CPU
No.2)
• Specifies the maximum number of blocks used for the multiple CPU
high-speed transmission dedicated instruction (target CPU=CPU No.2).
When the dedicated instruction of Multiple CPU transmission is
executed to the CPU No.2, and the number of empty blocks of the
dedicated instruction transmission area is less than the setting value of
this register, SM797 is turned ON, which is used as the interlock signal
for consecutive execution of the dedicated instruction of Multiple CPU
transmission.
U (At 1 scan
after RUN)
New
SD798
Maximum
number of blocks
used for the
multiple CPU
high-speed
transmission
dedicated
instruction
setting (for CPU
No.3)
• Specifies the maximum number of blocks used for the multiple CPU
high-speed transmission dedicated instruction (target CPU=CPU No.3).
When the dedicated instruction of Multiple CPU transmission is
executed to the CPU No.3, and the number of empty blocks of the
dedicated instruction transmission area is less than the setting value of
this register, SM798 is turned ON, which is used as the interlock signal
for consecutive execution of the dedicated instruction of Multiple CPU
transmission.
U (At 1 scan
after RUN)
New
SD799
Maximum
number of blocks
used for the
multiple CPU
high-speed
transmission
dedicated
instruction
setting (for CPU
No.4)
• Specifies the maximum number of blocks used for the multiple CPU
high-speed transmission dedicated instruction (target CPU=CPU No.4).
When the dedicated instruction of Multiple CPU transmission is
executed to the CPU No.4, and the number of empty blocks of the
dedicated instruction transmission area is less than the setting value of
this register, SM799 is turned ON, which is used as the interlock signal
for consecutive execution of the dedicated instruction of Multiple CPU
transmission.
U (At 1 scan
after RUN)
New
