Mitsubishi Q01CPU User Manual

App - 2
Appendix 1 External Dimensions
Appendix 1.1 CPU module
APPENDICES
(2) Q00CPU,Q01CPU,Q02CPU,Q02HCPU,Q06HCPU,Q12HCPU,Q25HCPU,
Q02PHCPU, Q06PHCPU, Q12PHCPU,Q25PHCPU, Q02UCPU,
Q03UDCPU, Q04UDHCPU, Q06UDHCPU,Q13UDHCPU,Q26UDHCPU
(3) Q03UDECPU,Q04UDEHCPU,Q06UDEHCPU,Q13UDEHCPU,Q26UDEHCPU
Unit : mm (inch)
Diagram App.2 Q00CPU,Q01CPU,Q02CPU,Q02HCPU,Q06HCPU,Q12HCPU,Q25HCPU,Q02PHCPU,Q06PHCPU,
Q12PHCPU,Q25PHCPU,Q02UCPU,Q03UDCPU,Q04UDHCPU,Q06UDHCPU, Q13UDHCPU,
Q26UDHCPU
Unit : mm (inch)
Diagram App.3 Q03UDECPU,Q04UDEHCPU,Q06UDEHCPU,Q13UDEHCPU,Q26UDEHCPU
89.3 (3.52)
98
(3.86)
4
(0.16)
Q02HCPU
RS-232
USB
MODE
RUN
ERR.
USER
BAT.
BOOT
27.4
(1.08)
PULL
23 (0.92)
(3.86)
98
4
(0.16)
23 (0.92)
27.4
(1.08)
115 (4.53)

Mitsubishi Q01CPU Specifications

General

Brand	Mitsubishi
Model	Q01CPU
Category	Controller
Language	English
