Appendix 1 External Dimensions
Appendix 1.1 CPU module
APPENDICES
(5) When Q7BAT-SET is mounted on CPU module
Unit : mm (inch)
Unit : mm (inch)
Diagram App.5 When Q7BAT-SET is mounted on CPU module
98 (3.86)30 (1.18)
27.4
(1.08)
89.3 (3.52)
PULL
RUN
ERR.
BAT.
BOOT
USER
MODE
Q25HCPU
Q7BAT-SET
MODEL
LITHIUM BATTERY
USB
RS-232
TRACKING
Q25PRHCPU
PULL
USB
RS-232
Q7BAT-SET
MODEL
LITHIUM BATTERY
98 (3.86)
30 (1.18)
27.4
(1.08)
89.3 (3.52)
RUN
ERR.
BAT.
BOOT
USER
MODE
CONTROL
SYSTEM A
SYSTEM B
BACKUP
2
(0.08)
