- 8
Appendix 1 External Dimensions
Appendix 1.2 Power supply module
APPENDICES
(5)
Q63RP
(6)
Q64RP
Unit : mm (inch)
Diagram App.1
1 Q63RP
Unit : mm (inch)
Diagram App.12 Q64RP
98 (3.86)
83 (3.27)
Q63RP
PULL
POWER
115 (4.53)
98 (3.86)
83 (3.27)
Q64RP
PULL
POWER
115 (4.53)
693
