5 - 18 5 - 18
MELSEC-Q
5 ASSIGNMENT OF I/O NUMBERS
(b) I/O assignment with GX Developer
Designate the head I/O number of slot No. 3 to "200" and that of slot No. 4
to "70" at the "I/O assignment" tab screen of GX Developer.
"200" is designated as the
head I/O number.
"70" is designated as the head
I/O number.
(When the head I/O number
is not designated, the I/O
number following the 3rd slot
will be assigned.)
(c) I/O number assignment after the I/O assignment with GX Developer
01234
Q38B
9101112
Q68B
8 13 14 15
F0
10F
110
12F
130
14F
150
16F
170
17F
Y180
Y19F
Y1A0
Y1BF
Y1C0
Y1DF
1
567
X00
X1F
X20
X3F
X40
X5F
X200
X21F
Y70
Y8F
Y90
YAF
YB0
YCF
YD0
YEF
Power supply module
32
points
Input module
Input module
Input module
Output module
Output module
32
points
32
points
32
points
32
points
Output module
Output module
32
points
32
points
Input module
32
points
IN OUT
Power supply module
Intelligent
function module
Intelligent
function module
Output module
Output module
Output module
32
points
32
points
32
points
32
points
16
points
32
points
32
points
32
points
Intelligent
function module
Intelligent
function module
Empty
CPU module
5.8 Checking the I/O Numbers
System monitor of GX Developer allows the check of the mounted modules of High
Performance model QCPU and their I/O numbers. (For system monitor, refer to
Section 7.18.)
