7 - 87 7 - 87
MELSEC-Q
7 FUNCTION
Processing Item Processing Time
Buffer memory write
(1) Main base
(a) 16 words or less:
Time = 0.47
(total number of transferred words) 2.65 (number of
settings)
0.95
(b) More than 16 words:
Time = 0.55 (total number of transferred words) 0.95
(2) Extension base
(a) 16 words or less:
Time = 1.07
(total number of transferred words) 2.65 (number of
settings) + 0.95
(b) More than 16 words:
Time = 1.15
(total number of transferred words) 0.95
(Calculation example) 4.54
s when the module is mounted on the main base,
the number of settings is 1, and the number of words is 2
Y output
(1) Main base
Time = 0.13 (total number of Y points) 1.55
(2) Extension base
Time = 0.2
(total number of Y points) 1.55
(Calculation example) 3.63 s when the module is mounted on the main base,
the number of settings is 1, and the number of Y points is 16
To Next Page
