2 - 17 2 - 17
MELSEC-Q
2 USING THE E-MAIL FUNCTION
(3) Sample program
The following shows a sample program for sending e-mails by the PLC CPU.
Perform e-mail send processing using the send command (X20).
The contents of the send data are shown in (4).
When I/O signals of the Ethernet module are X/Y00 to X/Y1F.
Designate ASCII as the send
data format.
Designate the send destination
number.
Designate the send data length.
Designate the subject length.
Designate subject.
Send the e-mail.
Designate the attached file.
Processing program when normal completion
Processing program when abnormal completion
REMARK
When an error occurs while sending e-mail from the sending mail server to an
external device, an error code is stored in the receiving error log area.
To Next Page
