11.2 RACKS WITH EXPOSITION LIGHTING
FLUORESCENT LAMPS
Name CLIMACELL E 111 / 111-c 222 / 222-c 404 / 404-c 707 / 707-c 1212 / 1212-c
Width x depth x height of rack mm 539x350x90 539x500x123 539x500x123 939x512x93 539x500x123
Number of fl uorescent lamps per 1 rack pc 5 8 8 12 8
Max. number of racks in a chamber pc 2 / 2 2 / 2 3 / 4 3 / 4 12 / 12
Input per 1 rack W 75 120 120 180 120
length x diameter of fl uorescent lamp mm 450 / 26
Usable VIS source (fl uorescent lamp):
range // colour temperature
400 - 700 nm // 2700 / 3000 / 4000 / 6000 °K
Usable UV source (fl uorescent lamp):
range // maximum
300 - 400 nm // maximum 350 nm
Exposition parameters VIS
Tube type / input W/pc Luxline Plus - colour temperature 4000°K // 15 W
Lighting: in the centre of the storage
rack below the source, in the distance
from light source: 10 cm
klux ±10 % 16,5 18 18 20 18
Exposition parameters UV
Tube type / input W/pc Black light blue BLB // 15 W
Lighting: in the centre of the storage
rack below the source, in the distance
from light source: 10 cm
mW/cm
2
±10 % 5
Coverage according to EN 60529 IP 65
Number of connectors per 1 rack pc 2 2 2 4 2
Operation temperature range: rack ON, humidity OFF
1 rack °C 0 - 100 / 0 - 100 / 0 - 100 / 0 - 100 /
2 racks °C 15 - 100 / 15 - 100 /
3 racks °C xx xx 8 - 100 / 8 - 100 /
4 racks °C xx xx xx xx
12 racks °C xx xx xx xx
Operation temperature range : rack ON, humidity ON
1 rack °C 10 - 90 / 10 - 90 / 10 - 90 / 10 - 90 /
2 racks °C 17 - 90 / 15 - 90 /
3 racks °C xx xx 15 - 90 / 15 - 90 /
4 racks °C xx xx xx xx
12 racks °C xx xx xx xx
Controlled relative humidity range: rack ON (applies to temperature range 15 - 50 °C)
1 rack % RH 10 - 75 / 10 - 75 / 10 - 85 / 10 - 85 /
2 racks % RH 10 - 60 / 10 - 60 /
3 racks % RH xx xx 10 - 60 / 10 - 60 /
4 racks % RH xx xx xx xx
12 racks % RH xx xx xx xx
Operation temperature and relative humidity range: rack OFF, humidity ON
Temperature °C 10 - 90
RH % RH 10 - 95
All the data apply in empty chamber (without samples on screens) for ambient temperature of 20 - 22 °C, 100 % fan revolutions,
feeding voltage 230 V ± 10 %.
Current values of photometric items in the course of the experiment must be measured by an independent measuring gauge.
Instructions for use
46 CLIMACELL EVO_np_en_1401_mmm_V1.01
