1 PRODUCT NAME
The Instructions for use apply to the below stated device
models:
Type Model Trade Name ZP Type Construction
Design
CLC - E CLC kkk-c CLIMACELL - Evo automatics –
touch screen
E – EVO (Evolution)
kkk – chamber size 111, 222, 404, 707, 1212
c – cooling up to -20 °C.
2 PURPOSE AND USE
The device CLIMACELL EVO is designed for applications
requiring precise and reproducible simulation of variable
climatic conditions. In its basic version, the incubator allows
simultaneous regulation of temperature and humidity. In
case of additional equipment purchase it offers regulations
of concentration of CO
2
respectively other gases or space
– homogenous lighting in the fi eld of visible or UV light with
adjustable intensity and possibility of intensity measuring
using special sensors. Thanks to the unique combination
the device offers the user with extensive possibilities of use.
CLIMACELL EVO can be used in biology, food processing
industry, chemical industry, electrical technology, histology,
botany, pharmacy and others. A typical example may be the
cultivation of plant and tissue cultures or tests of stability
(photo stability) of materials and medicaments.
2.1 BASIC CHARACTERISTICS
● In the operation space of the device it is possible to
simulate the environment with temperature 0 up to
100 °C (-20 °C up to 100 °C for model „c“), relative
humidity (hereinafter referred to as RH) 10 % up to
95 %. For possible combinations of temperature and RH
see chapter 8.4.5 .
● Possibility of chamber decontamination / sterilization at
160 °C.(this function is not designed for sterilisation of
samples or material).
● Control of space – homogenous lighting with wave
length in visible and UV zone. The light exposition may
be monitored using optional sensors.
● Regulation of CO
2
in the range from 0 up to 20 %
(0-2000 ppm), max. temperature 55 °C. (respectively of
other gases).
● Temperature, RH, lighting and concentration of CO
2
(respectively of other gases) may be regulated in various
time modes.
● Tested samples are stored on racks supplied together
with the device.
● The unique system of air circulation with forced
circulation guarantees space – homogenous distribution
of temperature and RH in the whole operation space of
the device.
● Set speeed of fan from 0 to 100 % in ten – percent
intervals.
● The chamber and all the inner parts are made of
stainless steel. The outer shell is made partially of
zinc-coated and stainless steel material and it is treated
with water-soluble stove enamel (environment - friendly).
● CLIMACELL EVO is equipped with a multi-processor
control with the following characteristics:
o Precise regulation of temperature, humidity, lighting
and CO
2
(gas) with application of the newest trends
in the fi eld of regulation (fuzzy logic), supported by
many years of experience of the company BMT in
this fi eld.
o Graphic display with touch panel allows simple and
intuitive control.
o Wide offer of communication interfaces - Ethernet,
Wifi , USB, RS232. – according to optional equipment
o As many as 100 freely adjustable programs.
Each program may consist from up to 100 partial
segments.
o Possibility of structuring the users into groups with
differentiated access rights to the operation and
service settings of the device.
o In internal memory of the device there is
automatically saved the record of the course
of regulation including audit trail, total length of
recording up to one year.
o The user has the possibility to make backup of some
device settings and record of the regulation on the
SDHC card, fl ash disc or some other large-capacity
memory USB device.
o Support of WarmComm4 software for regulation
progress recording.
Instructions for use
CLIMACELL EVO_np_en_1401_mmm_V1.01 3
