Mobotix D24M - D24 M It;Secure: Delivered Parts, Components, Dimensions; Delivered Parts and Camera Components of D24 M It;Secure

42


www.mobotix.com • sales@mobotix.com
2.2 
 
Item  
1.1 1 Camera housing
1.2 1 Lens
1.3 1 Lock ring
1.4 1 Dome, transparent
1.5 1 CAT5 Ethernet cable, 0.5 m, pre-installed
1.6 1 Allen wrench 3mm
1.7 1 Hook wrench
1.8 1 Outer shell with rubber seal
1.9 1 Mounting ring (image not shown)
1.10 4 Universal screw anchors 8 mm
1.11 4 Stainless steel washers Ø 5.3mm
1.12 4 Stainless steel Torx screws 4.5x60 mm
1.13 1 Torx wrench TX20
1.14 4 Allen screws M4x16 mm
1.15 4 Stainless steel washers Ø 4.3mm
