Mounting The Camera With The On-Wall Set
© MOBOTIX AG • Security-Vision-Systems • Made in Germany
www.mobotix.com • sales@mobotix.com
Scope Of Delivery And Required Parts
Please check that all components supplied with the On-Wall Set are present in the original
packaging first.
The Following Additional Tools Are Required For Installation:
• Suitable materials for ceiling/wall installation: 4 wood screws incl. screw anchors
and washers (e.g. from the original camera packaging).
• Screwdriver
• Power drill for screw anchor holes needed for ceiling/wall mounting
• MOBOTIX Drilling Templates (at the end of this manual)
• Scissors to cut out the template
• Pen to mark the drill holes
• Materials and tools needed to connect the pre-installed MOBOTIX network cable in
the camera with the on-site network cable.
• Soft cotton cloth to clean the front of the lens
