LED indicators
49
12/03 AWB-C27-1293GB
Various models
LED indicators which are marked with a symbol or
text:
Symbol Designation Colour Status Function
Alarm Red Off No alarm active
On Alarm active
Flashing Alarm (confirmation required)
Com Green On Communication OK
Flashing Communication error
– Green – Programmable with macro editor
Run Green Off Hardware fault
On OK
Fault – Off Hardware OK
On Hardware fault
Flashing Battery low
Red Off Hardware OK
On Hardware fault
Flashing Battery low
Green Off No key pressed
On Key pressed
