Moeller MI4 - Technical Data

Operation
56
12/03 AWB-C27-1293GB
Technical data
General
Standards EN 61 131-2, EN 50 178
Shock resistance 15 g/11 ms
Vibration resistance Constant 1g, f = 0 to 150 Hz
Cable cross-section 0.22 to 1.5 mm
2
EMC See below
Ports
PC/PRINTER PORT
Type RS 232
Transmission rate 600 to 38400 kbit/s
Plug type 15-pin, Sub-D socket
PLC PORT
PLC/PC PORT
Type RS 232, RS 485
Plug type 15-pin, Sub-D plug
AUX PORT
Type Depending on connected
interface module
Plug type 9-pin, Sub-D socket
General electromagnetic compatibility (EMC) data for automation devices
Emitted interference EN 55 011/22 Class A
Interference immunity
ESD EN 61 000-4-2 Contact discharge
Air discharge
4 kV
8 kV
RFI EN 61 000-4-3 AM/PM 10 V/m
Burst EN 61 000-4-4 Network/digital I/O
Analog I/O, field bus
2 kV
1 kV
Surge EN 61 000-4-5 Digital O/O, asymmetrical
Network DC, asymmetrical
Network DC, symmetrical
Network AC, asymmetrical
Network AC, symmetrical
0.5 kV
1 kV
0.5 kV
2 kV
1 kV
Line-conducted
interference
EN 61 000-4-6 AM 10 V
