Communication cables
55
12/03 AWB-C27-1293GB
Text operator panel (with PC/PRINTER PORT)
Graphic/touch operator panel
햲 Other interface modules can be connected in place of
the Suconet K module:
PROFIBUS-DP ZB4-504-IF1
Siemens MPI ZB4-505-IF1/-IF2
DeviceNet ZB4-506-IF1
CANopen ZB4-507-IF1
For cable assignments of these interfaces, see section
“Engineering”. For an overview, see page 12.
* The following units are supplied with a fitted Suconet-K
interface (ZB4-501-IF1):
MI4-101-KC1
MI4-101-KE1/MI4-111-KE1
MI4-131-KH1
MI4-151-KF1/MI4-451-KF1
MI4-151-TA1/MI4-451-TA1
MI4-161-TC1/MI4-471-TC1
RS 232 RS 232/RS 485
PC/PRINTER
PORT
MI4 PLC PORT AUX PORT
Sucom A Suconet K* Other
interface
modules
ZB4-24A-KP1 ZB4-2B3-KB1 ZB4-2B7-KB1 ZB4-2B3-KB2 ZB4-231-KB1 ZB4-233-KB2
햲
RS 232 RS 232 RS 232 RS 485 RS 485 RS 485
PC PS416-CPU PS4-150
PS4-200
PS4-300
PS416-CPU PS4-150
PS4-200
PS4-300
PS416 XC100/
200/600
Non-
Moeller
devices
