Moeller MI4 - Graphics-Capable Text Operator Panel

Technical data
61
12/03 AWB-C27-1293GB
Graphics-capable text operator panel
MI4-...
110-KC1 110-KD1 110-KG2 110-KG1 140-KF1 140-KI1 140-KJ1
Display Monochrome
LCD
Monochrome
LCD
Monochrome
LCD
Monochrome
LCD
Monochrome
LCD
Monochrome
LCD
Monochrome
LCD
Backlighting LED LED LED LED LED LED LED
Contrast adjustment Software Software Software Software Software Software Software
Graphics capability Yes Yes Yes Yes Yes Yes Yes
Number of colours/grey
levels
––– ––––
Rows x characters 4 x 20 4 x 20 4 x 20 4 x 20 8 x 20 8 x 40 8 x 40
Resolution in pixels 120 x 32 120 x 32 120 x 32 120 x 32 120 x 64 240 x 64 240 x 64
Display dimensions 70 x 21 mm 70 x 21 mm 70 x 21 mm 70 x 21 mm 66 x 33 mm 127 x 34 mm 127 x 34 mm
Scaleable font Yes Yes Yes Yes Yes Yes Yes
User-definable
characters
256 256 256 256 256 256 256
Keys
Numeric keypad – Yes Yes Yes Yes Yes Yes
F-keys (with LED),
labelling facility
4 9 12 12 9 23 23
Total number of user-
programmable keys
11 19 35 35 27 46 46
Electromechanical
keypads can be fitted
––– –––Yes
User LEDs 4 1013 13212432
Touch function ––– ––––
