Moeller MI4 - Graphic Operator Panels

Technical data
65
12/03 AWB-C27-1293GB
Graphic operator panels
MI4-151-KF1 MI4-451-KF1 MI4-150-KI1 MI4-450-KI1 MI4-170-KH1 MI4-570-KH1
Display Monochr. LCD Colour LCD-STN Monochr. LCD Colour LCD-STN Monochr. LCD TFT
Backlighting CCFL CCFL CCFL CCFL CCFL CCFL
Contrast adjustment Autom. Autom. Software Software Software Software
Graphics capability Yes Yes Yes Yes Yes Yes
Number of colours/grey levels – 16 – 16 – 256
Rows x characters 16 x 40 16 x 40 16 x 40 16 x 40 30 x 80 30 x 80
Resolution in pixels 320 x 240 320 x 240 320 x 240 320 x 240 640 x 480 640 x 480
Display dimensions in mm 121 x 91/5.6" 121 x 91/5.6" 121 x 91/5.6" 121 x 91/5.6" 212 x 159/10,4“
Scaleable font Yes Yes Yes Yes Yes Yes
User-definable characters 256 256 256 256 256 256
Keys
Numeric keypad Yes Yes Yes Yes Yes Yes
F-keys (with LED), labelling facility 10 10 33 (24 – 33 no LED) 23 23
Total number of user-programmable
keys
37 37 56 56 50 50
User LEDs 10 10 24 24 24 24
Touch function – – – – – –
Memory
Flash project memory 512 kb (64 kb reserved for protocol) 8 MB SSFDC card 8 MB SSFDC card
Recipe memory 32 kb 32 kb 32 kb 32 kb 32 kb 32 kb
